For Superconductors, Discovery Comes From Disorder

The original Argonne press release by Jared Sagoff can be read here.

Discovered more than 100 years ago, superconductivity continues to captivate scientists who seek to develop components for highly efficient energy transmission, ultrafast electronics or quantum bits for next-generation computation.  However, determining what causes substances to become — or stop being — superconductors remains a central question in finding new candidates for this special class of materials.

In potential superconductors, there may be several ways electrons can arrange themselves. Some of these reinforce the superconducting effect, while others inhibit it. In a new study, scientists at the U.S. Department of Energy’s (DOE) Argonne National Laboratory have explained the ways in which two such arrangements compete with each other and ultimately affect the temperature at which a material becomes superconducting.

In the superconducting state, electrons join together into so-called Cooper pairs, in which the motion of electrons is correlated; at each moment, the velocities of the electrons participating in a given pair are opposite. Ultimately, the motion of all electrons is coupled — no single electron can do its own thing — which leads to the lossless flow of electricity: superconductivity.

Generally, the more strongly the pairs couple and the larger the number of electrons that participate, the higher will be the superconducting transition temperature.

The materials that are potential high-temperature superconductors are not simple elements, but are complex compounds containing many elements. It turns out that, besides superconductivity, electrons may exhibit different properties at low temperatures, including magnetism or charge density wave order. In a charge density wave, electrons form a periodic pattern of high and low concentration inside the material. Electrons that are bound in the charge density wave do not participate in superconductivity, and the two phenomena compete.

“If you remove some electrons to put into a charge density wave, the strength of your superconducting effect will diminish,” said Argonne materials scientist Ulrich Welp, a corresponding author of the study.

The work of the Argonne team is based on the realization that charge density wave order and superconductivity are affected differently by imperfections in the material. By introducing disorder, the researchers suppressed a charge density wave, disrupting the periodic charge density wave pattern while having only a small effect on superconductivity. This opens a way to tune the balance between the competing charge density wave order and superconductivity.

To introduce disorder in such a way that impaired the charge density wave state, but left the superconducting state largely intact, the researchers used particle irradiation. By hitting the material with a proton beam, the researchers knocked out a few atoms, changing the overall electronic structure while keeping the chemical composition of the material intact.

To get a picture of the fate of the charge density waves, researchers utilized state-of-the-art X-ray scattering at the X-ray Science Division (XSD) 6-ID-B x-ray beamline at the Advanced Photon Source (APS), an Office of Science user facility at Argonne, and the Cornell High Energy Synchrotron Source. ​“X-ray scattering was essential to observe the subtleties of this electronic order in the material,” said Argonne physicist and study author Zahir Islam of the XSD Magnetic Materials Group. ​“We discovered that a dilute concentration of disordered atoms really diminished the charge density wave to enhance superconductivity.”

According to Islam, while the current brilliance of the APS allowed for systematic studies of charge density waves from tiny single-crystal samples despite its relatively weak scattering strength, the upcoming upgrade to the facility will afford researchers utmost sensitivity to observe these phenomena. Furthermore, he said, scientists will benefit from studying these materials in extreme environments, in particular, under high magnetic fields to tip the balance in favor of charge density waves to gain necessary insights into high-temperature superconductivity.

In the research, the scientists investigated a material called lanthanum barium copper oxide (LBCO). In this material, the superconducting temperature plummeted almost to absolute zero (-273 degrees Celsius) when the material achieved a certain chemical makeup. However, for closely related compositions, the transition temperature remained relatively high. The scientists believe this effect of chilling superconductivity is due to the presence of charge density waves and that suppressing the charge density wave could induce even higher transition temperatures.

With charge density waves impaired by disorder, superconductivity reaps the benefit, Wai-Kwong Kwok, Argonne Distinguished Fellow and study author, explained. ​“From the perspective of the superconductor, the enemy of my enemy truly is my friend,” he said.

See: Maxime Leroux, Vivek Mishra, Jacob P.C. Ruff, Helmut Claus, Matthew P. Smylie, Christine Opagiste, Pierre Rodière, Asghar Kayani, G.D. Gu, John M. Tranquada, Wai-Kwong Kwok, Zahirul Islam, Ulrich Welp, "Disorder raises the critical temperature of a cuprate superconductor," Proc. Natl. Acad. Sci. USA 116 (22), 10691-10697 (2019). DOI: 10.1073/pnas.1817134116

This research used resources of the Advanced Photon Source, a U.S. Department of Energy (DOE) Office of Science User Facility operated for the DOE Office of Science by Argonne National Laboratory under Contract No. DE-AC02-06CH11357.d modified classical nucleation theory to investigate the discrepancy between these ideas.
